Baudouin Powered Diesel Generators

Our diesel generator sets are powered by genuine Baudouin engines, a French brand with over a century of expertise in diesel power solutions. Known for their strong performance and operational stability, they are designed to deliver consistent output across a wide range of applications.

Frequency 50Hz 60Hz
Prime Power 18-2000kVA (15-1600kW) 23-1988kVA (18-1600kW)
Standby Power 20-2250kVA (16-1800kW) 25-2188kVA (20-1750kW)
Fuel Consumption 4.7-424.0L/h 6.5-496.5L/h
Displacement 2.3-52.3L 2.3-52.3L
Request a Quote

Meeting stringent international emission standards such as EU Stage IIIA and IMO Tier II, these gensets combine fuel efficiency with low operating costs. Their engineering ensures consistent operation even under demanding conditions, making them well-suited for marine vessels, industrial facilities, commercial complexes, and critical backup systems. Built with a focus on durability and long service life, Baudouin gensets are a practical choice for operations that require both high power density and reliable 24/7 performance. Whether deployed as prime power or standby units, they provide a steady and efficient energy supply, proving to be suitable as an effective power supply solution in even the most challenging environments.

Technical Specifications
50Hz Diesel Generator Sets
Genset Model Prime Power Standby Power Engine Model Fuel Consumption Cylinder Displacement
kVA kW kVA kW L/h L
CDB20 18 15 20 16 4M06G20/5 4.7 4L 2.3
CDB20-1 18 14 20 16 4M08G2D3/5 4.8 4L 3.2
CDB23 20 16 23 18 4M08G4D3/5 6.4 4L 3.2
CDB25 23 18 25 20 4M06G25/5 6.7 4L 2.3
CDB35 32 26 35 28 4M06G35/5 7.6 4L 2.3
CDB38 30 24 38 30 4M08G8D3/5 8.6 4L 3.2
CDB42 38 30 45 36 4M08G10D3/5 10.9 4L 3.2
CDB44 40 32 44 35 4M06G44/5 9.5 4L 2.3
CDB50 45 36 50 40 4M06G50/5 10.7 4L 2.3
CDB55 50 40 55 44 4M06G55/5 11.9 4L 2.3
CDB69 63 50 69 55 4M10G2D3/5 14.3 4L 4.1
CDB72 65 52 72 57 4M10G70/5 15 4L 4.1
CDB88 80 64 88 70 4M10G88/5 18.8 4L 4.1
CDB88-1 80 64 88 70 4M10G4D3/5 17.3 4L 4.1
CDB110 100 80 110 88 4M10G110/5 21.3 4L 4.1
CDB110-4 100 80 110 88 4M10G6D3/5 25 4L 4.1
CDB125 100 80 125 100 4M10G125/5^ 24 4L 4.1
CDB125-1 113 90 125 100 4M12G1D3/5 23.6 4L 5
CDB150 125 100 150 120 4M12G2D3/5 31.7 6L 4.6
CDB150-1 135 108 150 120 6M11G150/5 30.2 6L 6.8
CDB165-1 150 120 165 132 4M12G4D3/5 31.7 6L 4.6
CDB165 150 120 165 132 6M11G165/5 32.6 6L 6.8
CDB188 168 135 188 150 6M11G188/5 35 6L 6.8
CDB200 188 150 200 160 6M12G2D3/5 39.7 6L 7.5
CDB220 200 160 220 176 6M16G220/5 43.1 6L 9.7
CDB250-1 225 180 250 200 6M12G6D3/5 51.5 6L 7.5
B250 230 184 250 200 6M16G250/5 50.9 6L 9.7
CDB275 250 200 275 220 6M16G275/5 56.9 6L 9.7
CDB275-1 250 200 275 220 6M12G8D3/5 53.4 6L 7.5
CDB300 275 220 300 240 6M16G300/5 60 6L 9.7
CDB350 320 256 350 280 6M16G350/5 70.5 6L 9.7
CDB350-1 313 250 350 280 6M16G8D3/5 66.8 6L 9.7
CDB385 350 280 385 308 6M21G400/5 82.1 6L 12.5
CDB400 375 300 400 320 6M21G2D3/5 81.2 6L 12.5
CDB440 400 320 440 352 6M21G440/5 85.5 6L 12.5
CDB500 450 360 500 400 6M21G500/5 110.1 6L 12.5
CDB500- 438 350 500 400 6M21G6D3/5 92.9 6L 12.5
CDB550 500 400 550 440 6M21G550/5 1,095 6L 12.5
CDB550-1 500 400 550 440 6M21G8D3/5 110.1 6L 12.5
CDB660 600 480 660 528 6M33G660/5 126.5 6L 19.6
CDB715 650 520 715 572 6M33G715/5 136.3 6L 19.6
CDB725 650 520 725 580 6M33G6D3/5 80 6L 19.6
CDB750 680 544 750 600 6M33G750/5 151.1 6L 19.6
CDB813 750 600 813 650 6M33G8D3/5 154 6L 19.6
CDB825 750 600 825 660 6M33G825/5 161.5 6L 19.6
CDB875 800 640 875 700 12M26G900/5 190 12V 31.8
CDB875-1 800 640 875 700 8M33G2D3/5 177 8V 26.1
CDB900 815 652 900 720 8M33G900/5 174.2 8V 26.1
CDB1000 900 720 1000 800 8M33G1000/5^ 194.1 8V 26.1
CDB1000- 900 720 1000 800 12M26G1000/5 195.5 12V 31.8
CDB1000-1 900 720 1000 800 8M33G4D3/5 195.5 8V 26.1
CDB1100 1000 800 1100 880 8M33G1100/5 200 8V 26.1
CDB1100- 1000 800 1100 880 8M33G6D3/5 207 8V 26.1
CDB1120 1020 816 1120 898 12M26G1100/5 207.1 12V 31.8
CDB1250 1150 920 1250 1000 12M33G1250/5 236.2 12V 39.2
CDB1250-l 1125 900 1250 1000 12M33G6D3/5 245 12V 39.2
CDB1375 1250 1000 1375 1100 12M33G8D3/5 304 12V 39.2
CDB1400 1250 1000 1400 1120 12M33G1400/5 258.6 12V 39.2
CDB1500 1375 1100 1500 1200 12M33G1500/5 296.9 12V 39.2
CDB1500 1375 1100 1500 1200 12M33G10D3/5 312 12V 39.2
CDB1650 1500 1200 1650 1320 12M33G1650/5 324 12V 39.2
CDB1650- 1500 1200 1650 1320 12M33G14D3/5 312 12V 39.2
CDB1900 1750 1400 1900 1520 16M33G1900/5 364.3 16V 52.3
CDB1900- 1750 1400 1900 1520 16M33G4D3/5 609 16V 52.3
CDB2000 1875 1500 2000 1600 16M33G2000/5 401 16V 52.3
CDB2063 1875 1500 2063 1650 16M33G6D3/5 427 16V 52.3
CDB2250 2000 1600 2250 1800 16M33G2250/5^ 485.3 16V 52.3
CDB2250-1 2000 1600 2250 1800 16M33G8D3/5^ 424 16V 52.3
60Hz Diesel Generator Sets
Genset Model Prime Power Standby Power Engine Model Fuel Consumption Cylinder Displacement
kVA kW kVA kW L/h L
CDB254 23 18 25 20 4M06G20/6 6.5 4L 2.3
CDB32 29 23 32 25 4M06G25/6 7.3 4L 2.3
CDB42- 38 30 42 33 4M06G33/6 9.3 4L 2.3
CDB51 47 37 51 41 4M06G41/6 10.9 4L 2.3
CDB63 56 45 63 50 4M06G50/6 13.1 4L 2.3
CDB69 63 50 69 55 4M06G55/6 14.4 4L 2.3
CDB100 94 75 100 80 4M10G83/6 21.6 4L 4.1
CDB125-1 112 90 125 100 4M10G105/6 26.0 4L 4.1
CDB170 150 120 170 135 6M11G135/6 34.2 6L 6.8
CDB200-1 181 145 200 160 6M11G160/6 40.0 6L 6.8
CDB220-1 200 160 220 175 6M11G176/6 48.6 6L 6.8
CDB250-ll 225 180 250 200 6M16G200/6 51.2 6L 9.7
CDB275-IⅢ 250 200 275 220 6M16G220/6 56.5 6L 9.7
CDB313 285 227 313 250 6M16G250/6 62.6 6L 9.7
CDB385 350 280 385 308 6M16G308/6 88.9 6L 9.7
CDB413 375 300 413 330 6M21G330/6 82.3 6L 12.5
CDB488 438 350 488 390 6M21G390/6 98.1 6L 12.5
CDB500-II 455 360 500 400 6M21G400/6 114.3 6L 12.5
CDB575 500 400 575 460 6M21G460/6 109.6 6L 12.5
CDB719 650 520 719 575 6M33G575/6 139.0 6L 19.6
CDB750 688 550 750 600 6M33G600/6 150.7 6L 19.6
CDB800 719 575 800 640 6M33G633/6 180.1 6L 19.6
CDB825 750 600 825 660 6M33G660/6 193.7 6L 19.6
CDB875 875 700 875 770 8M33G770/6 195.0 6L 26.1
CDB1000-I1 900 720 1000 800 8M33G800/6 209.2 6L 26.1
CDB1000-1 900 720 1000 800 12M26G800/6 203.1 6L 31.8
CDB1125 1000 800 1125 900 12M26G900/6 217.3 6L 31.8
CDB1125-1 1000 800 1125 900 8M33G900/6^ 223.5 6L 26.1
CDB1250-11 1138 910 1250 1000 12M26G1000/6^ 290.0 6L 31.8
CDB1375-l 1250 1000 1375 1100 12M33G1100/6 278.7 6L 39.2
CDB1500-l 1365 1092 1500 1200 12M33G1200/6 336.6 6L 39.2
CDB1625 1470 1176 1625 1300 12M33G1300/6 369.5 6L 39.2
CDB2063-l 1875 1500 2063 1650 16M33G1650/6 382.8 6L 52.3
CDB2188 1988 1600 2188 1750 16M33G1750/6 496.5 6L 52.3
