Deutz Powered Diesel Generators

Our diesel generator sets is powered by Deutz engines and incorporates advanced emission control technologies such as EGR (exhaust gas recirculation) and SCR (selective catalytic reduction). Built to meet strict international emission standards such as EU Stage V and EPA Tier 4, these gensets deliver cleaner, more efficient operation while still packing plenty of power. With engine displacements of up to 15.87 liters, they can handle everything from heavy-duty industrial use to challenging on-site power demands with ease.

Frequency 50Hz
Prime Power 38-562kVA (30-450kW)
Standby Power 41-625kVA (33-500kW)
Fuel Consumption 195-230g/kW.h
Displacement 3.114-15.87L
Request a Quote
Specifications

Providing emergency power for critical infrastructure, a prime electricity source in remote locations, or dependable energy for temporary construction sites, Deutz offers complete solutions for local power generation and decentralized energy supply needs. Whether for industrial, agricultural, or commercial use, these generator sets combine advanced technology, durable construction, and the trusted efficiency of Deutz engines to deliver consistent, high-quality power wherever it’s needed.

Technical Specifications
Genset Model CDD22KVA
Engine Model BFM3 G3
Prime Power 16 kW/20 kVA
Standby Power 17.6 kW/22 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD28KVA
Engine Model BFM3 G3
Prime Power 20 kW/25 kVA
Standby Power 22.4 kW/28 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD27KVA
Engine Model BFM3 G4
Prime Power 20 kW/25 kVA
Standby Power 21.6 kW/27 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD32KVA
Engine Model BFM3 G4
Prime Power 24 kW/30 kVA
Standby Power 25.6 kW/32 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD33KVA
Engine Model BFM3T G1
Prime Power 24 kW/30 kVA
Standby Power 26.4 kW/33 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD38KVA
Engine Model BFM3T G1
Prime Power 28 kW/35 kVA
Standby Power 30.4 kW/38 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD44KVA
Engine Model BFM3T G2
Prime Power 32 kW/40 kVA
Standby Power 35.2 kW/44 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD53KVA
Engine Model BFM3T G2
Prime Power 38 kW/47.5 kVA
Standby Power 42.4 kW/53 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD55KVA
Engine Model BFM3C G1
Prime Power 40 kW/50 kVA
Standby Power 44 kW/55 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD65KVA
Engine Model BFM3C G1
Prime Power 48 kW/60 kVA
Standby Power 52 kW/65 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD350KVA
Engine Model TCD12.1 G1
Prime Power 260 kW/325 kVA
Standby Power 280 kW/350 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD413KVA
Engine Model TCD12.1 G1
Prime Power 300 kW/375 kVA
Standby Power 330.4 kW/413 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD400KVA
Engine Model TCD12.1 G2
Prime Power 300 kW/375 kVA
Standby Power 320 kW/400 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD438KVA
Engine Model TCD12.1 G2
Prime Power 320 kW/400 kVA
Standby Power 350.4 kW/438 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD500KVA
Engine Model TCD13 G1
Prime Power 360 kW/450 kVA
Standby Power 400 kW/500 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD500KVA
Engine Model TCD13 G1
Prime Power 374.4 kW/468 kVA
Standby Power 400 kW/500 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD550KVA
Engine Model TCD13 G2
Prime Power 400 kW/500 kVA
Standby Power 440 kW/550 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD555KVA
Engine Model TCD13 G2
Prime Power 400 kW/500 kVA
Standby Power 444 kW/555 kVA
Speed 1800rpm
Frequency 60Hz
Genset Model CDD688KVA
Engine Model D17
Prime Power 500 kW/625 kVA
Standby Power 550.4 kW/688 kVA
Speed 1500rpm
Frequency 50Hz
Genset Model CDD688KVA
Engine Model D17
Prime Power 500 kW/625 kVA
Standby Power 550.4 kW/688 kVA
Speed 1800rpm
Frequency 60Hz
Specifications
  • Deutz Powered Diesel Generators
  • Deutz Powered Diesel Generators
  • Deutz Powered Diesel Generators
  • Deutz Powered Diesel Generators
  • Deutz Powered Diesel Generators
What operating modes are available for Deutz diesel generator sets?
  • Island mode operation: The generator set serves as the sole power source for the user’s system. This is ideal for locations without access to a public power grid or for users who choose to generate their own electricity, often making use of the heat produced by the generator when applicable.
  • Operation during power outages: In most cases, the user’s system is powered by the public grid. However, if the grid fails, the generator can automatically start to minimize disruptions or prevent material and financial losses in various sectors such as data centers, hospitals, and industrial facilities that require continuous operation.
  • Parallel operation in island mode: Multiple generator sets operate in parallel as the sole power source, enabling higher capacity and redundancy.

The standard maintenance interval is 500 hours. For gensets rated below 65 kVA, an extended maintenance option of up to 1,000 hours is available. Fuel consumption is optimized to save fuel and reduce operating costs.
